Cover Aspect Ratio Discussion #2139

Open
kruegp opened this issue Jul 17, 2023 · 9 comments
Open

Cover Aspect Ratio Discussion #2139

kruegp opened this issue Jul 17, 2023 · 9 comments
Labels
discussion In active discussion

Comments

@kruegp
Copy link

kruegp commented Jul 17, 2023

Description

This Github issue is to track further discussions related to the Maintain Cover Aspect Ratio Feature Request.

  • This issue was created after recommendation from discord

Considerations / Uses

  • thumbnails for covers (series, volumes, chapters, issues, ...) when displaying in library, search results, or within a series
  • thumbnails are used for generating combined image covers for collections

Patterns Other Apps Use

Displaying thumbnails for assets

  • komga
    • Example
    • as mentioned in the original feature request, komga seems to have a fixed height and width for the asset overlay, and the cover image is scaled to fit within the asset overlay (keeping the aspect ratio) (ie: containing)
      • additionally, the overlay background can be seen since the cover does not fill the overlay
      • additionally, the cover is centered
    • I believe this is similar to object-fit: contain
  • google search results
  • google play books
    • Example Garfield Series - Issues
    • Example Dune Series
    • seems to have a fixed width and a dynamic height (based upon the image height) for each asset overlay, the cover image is scaled to the fixed width (ie: fit)
      • additionally, the overlay background can not be seen since the cover is the same size as the overlay
      • additionally, the cover is centered horizontally and is justified to the bottom vertically
  • Theoretical - Justify Vertically
    • although I haven't see an existing example, one could follow a similar pattern to google play books, but fix the height and allow the width to by dynamic
  • Amazon Kindle Store
    • Example Garfield Books
    • follows the same pattern as komga (with a different fixed width and height
    • seems to have a fixed height and width for the asset overlay, and the cover image is scaled to fit within the asset overlay (keeping the aspect ratio) (ie: containing)
  • existing kavita behavior
    • seems to have a fixed height and width for the asset overlay, and the cover is scaled to fir the entire asset overlay (not maintaining the original aspect ratio) (ie: stretching)
    • I believe this is similar to object-fit: fill

Combined image collection covers

@kruegp kruegp added the needs-triage Needs to be triaged by a developer and assigned a release label Jul 17, 2023
@majora2007 majora2007 added discussion In active discussion and removed needs-triage Needs to be triaged by a developer and assigned a release labels Jul 17, 2023
@majora2007 majora2007 pinned this issue Jul 17, 2023
@majora2007
Copy link
Member

Thank you for adding a detailed post. To regurgitate what was discussed in discord. The original intent behind the change was to:

  1. Provide the ability to build merged covers (4 covers in a grid) for collections and reading lists
  2. Fix some stretching I was seeing in Comics and Webtoons and ensure all images fit in the UI nicely

As we discussed in discord, I did not consider things like Landscape books, which will always then have a bad cover in Kavita.

In terms of design, what we see in Komga and Amazon are no go for me. In my view, they do not look good and is not something I would want Kavita to have. I am 100% open to discussion and making a change as long as it will work on the majority of user material (books, webtoons, manga, and comics).

I will leave this to some discussion from the community.

@Ark1369
Copy link

Ark1369 commented Jul 22, 2023

Hello, I would like to add my opinions to the same.
The cover aspect Kavita features right now is sort of perfect when it comes to eastern literature in a way.
While webtoons on 1st glance look obviously bad due to those extreme long strips, that is a lost cause - whats important is official covers/season covers for these webtoons, they fit snugly in 2:3/68:100/7:10 which is very close to what Kavita features
Manhuas are same. (I have amassed roughly 1700 Volume/Manhwa Season covers officially to test)

So Kavita handles all the official covers of Manga (Full volume sleeves arent meant to be covers persay), Manhwa and Manhua rather well.
As per my limited knowledge Comics usually share the 2:3 aspect ratio for majority of the contents too.

So ultimately what could be the solution is - Inbuilt cropper for Kavita if possible, it would allow you to crop the cover out of Manhwa or crop the front of Manga Volume sleeve. (And this could serve as base for eventual set any picture inside cbz as cover - much like Tachiyomi features)

What I would actually like to be seen is, giving users an option to preserve the real quality of covers they upload/cbz dimensions instead of heavy forcefuly resize to 220x320. As on bigger screens it just looks extremely bad. (Option instead default so those who just want speed more instead quality on covers can keep it).

Komga one is inded worse of due to seeing backgrounds and whitespace when it forcefully resizes to fit in window.

@kruegp
Copy link
Author

kruegp commented Jul 26, 2023

In terms of design, what we see in Komga and Amazon are no go for me. In my view, they do not look good and is not something I would want Kavita to have. I am 100% open to discussion and making a change as long as it will work on the majority of user material (books, webtoons, manga, and comics).

Agreed. I think other options look better than those.

My personal preference would be to avoid stretching of the existing cover text / art

I think my top 2 choices would be:

  • (1) the original aspect ratio (similar to google play books)

    • overview
      • could give a fixed width and allow the height to be dynamic (with a max height option)
      • the collection cover could then be generated by stretching or cropping
    • tradeoffs
      • this would be the most flexible option (ie: if a user wanted to stretch or crop to a standard aspect ratio, they could always upload a new cover to the ui with their desired aspect ratio)
      • this would retain the original cover image
      • however - different titles with slightly different aspect ratios may look non-uniform (Example Dune Series)
  • (2) cropping (similar to google search results)

    • overview
      • could give a fixed width + height and crop images to fit that view
      • the collection cover could then be generated as is
    • tradeoffs
      • this would standardize the cover dimensions
      • this would not alter the original cover aspect ratio (of that displayed)
      • in a large number of cases, this would have minimal impact on the cover image since edges usually don't contain details (Example for Dune Series)
      • However - this may not be ideal for square / landscape books since it may cut off text from the title or key parts of the image (Example for Garfield Series)

There could also be opportunity to make this configurable (a global config)

  • if the thumbnails are persisted in the original aspect ratio, then based upon configuration / css, different display options could be utilized

Since there may be different use cases, perhaps a discord poll could be created to see if there is consensus / preference from a wider audience in discord.

  • If there is no consensus, that could imply exposing a global configuration for display options may be beneficial (or that users don't care much about this issue)

@howdy-im-david
Copy link

I know this discussion hasn't had input for a few weeks, but I wanted to chime in as primarily a western comic reader. I am also in favor of moving to keeping original aspect ratio intact.

@kruegp's Option (1) sums it up best, although I'll add that I don't personally feel that lack of uniformity is an issue. It could very well be artist/publisher intent to release something outside of the "standard" ratio for whatever creative reason and would be great to respect that as much as possible.

There's a few instances in Kavita's current UI where a fixed ratio creates a very undesirable result.

Reading lists highlight this best:


@takatak00
Copy link

Hi everyone, I would love to see a inbuilt cropper similar to Calibre for my Manga covers.

@majora2007
Copy link
Member

So I took a look with the latest code from v0.7.10 and here is what I found:

  • Garfield (Square cover)

  • Dune (non-standard, tall image)

  • Froggy (square cover)

  • Horizontal (longer in the width than height)

Overall, I don't really see much of a problem here. The issue is only present when there is a horizontal image which can get skewed, but the other image types have minimal skewing.

@sdaqo
Copy link

sdaqo commented May 21, 2024

I think as @majora2007 already said, it looks ok.
I would still like to chime in with some ideas. Also, I would like to preface this by saying: I do not know if this is handled client or server side, if client side my examples are a little useless, but oh well.

  1. For square (-ish) covers how about doing something like this
    This was generated by some python code from a project of mine:
def process_cd_cover(path: str):
    cover = Image.open(path)
    cover = crop_image(cover, 270, 270) # Edit: There is not really a need to crop here if it was already determined that the cover somewhat resembles a square, should probably rather be squashed/stretched

    background = Image.open(path)
    background = crop_image(background, 270, 400)
    background = background.filter(ImageFilter.GaussianBlur(8))

    background.paste(
        cover, (0, int((background.height - cover.height) / 2))
    )
    background.save(path, "JPEG")
  1. This may be a bit extreme but, how about using Seam Carving for cropping (Edit: I mean squashing/stretching) . I have no idea if this is feasable, but it looks cool :))

Example using https://trekhleb.dev/js-image-carver/:
Garfield before (I am only using a screenshot so the quality is kind of shit, maybe with better quality this looks even better):
Screenshot_20240521_211832
After Seam Carving, this does look a little weird, but the text is way more readable then the squashed example from above.

Another example:
Before:
Screenshot_20240521_223956
After:

  1. Someone said it already, but I also think cropping is a good idea!

@GlassedSilver
Copy link

GlassedSilver commented May 29, 2024

Not sure skewing images is something that is universally seen as acceptable in an app that otherwise prides itself with polish for its UI.

If the cover art is a given ratio that's just how it is. Comics and manga are often released in different aspect ratios and depending on what art is used the skewing can be less or very noticeable, especially with geometric forms.

I understand that nobody would insist on keeping a 299x102px image exactly like that, I think skewing (never cropping) that could be fine to fit into 300x100, but if we're talking different source aspect ratios rather than a suboptimally created file that's just a little off then skewing looks like a hack.

Just my two cents as non-developer though, so I voice this with upmost humbleness.

Edit: checked the linked PR. I agree that some cover art turns out better whilst other art won't. I thought of adjusting the grid layout for different aspect ratios, but I also realize that ai can't contribute code so back to my humbleness. :P

@majora2007 majora2007 moved this to To do in Backlog Aug 23, 2024
@heyhippari
Copy link
Contributor

  1. For square (-ish) covers how about doing something like this

This look great, I think, but I would still want a "cover fit" for tall images. Anything square-ish or wide could use this to avoid losing too much info (And maybe extremely tall images like webtoon strips could as well).

Generally, squashing images is pretty bad, but I get where @majora2007 is coming from with not losing too much info on the images either, hence the idea in the previous paragraph:

  • By default, UI uses a cover fit
  • When importing an image, figure out what the ratio is. If it strays "too far" from the ideal ratio (What "Too far" is is TBD), then build properly ratioed image with the original fitting inside perfectly, and the blank space being filled by a heavily blurred version

I think aesthetically, that's the best way to handle this.

This would also help with differences in the details pages, where the size of the cover changes: we could simply have the same ratio thing everywhere, and present a clean and consistent experience throughout.
